4000-662-888| Model | Studio Size(D*W*H)mm | Dimension(D*W*H)mm |
| LRHS-170M3-LJS | 10000×4880×3500 | 10400×5730×4230 |
| Temperature range | -40℃~+45℃ |
| Temperature fluctuation | ≤±1°C |
| Temperature uniformity | ≤±2°C |
| Heating rate | -40℃~+25℃,average rate 0.27℃/min |
| Cooling rate | +25℃~-40℃,average rate 0.27℃/min |
| Humidity range | 40%~85%RH |
| Outer box material | High-quality cold-rolled steel plate, surface plastic spraying treatment |
| Inside box material | Stainless steel plate SUS304 |
| Insulation material | Rigid polyurethane foam + glass fiber |
| Controller | Adopting Japan “UMC” brand temperature meter |
| Cooling method | Twin-combined refrigeration |
| Temperature and Humidity Sensor | High Accuracy Pt100 Platinum Resistance Temperature Sensors |
| Internal fan | 35mph±10%Speed of wind through the interior of the test chamber |
| Safety protection | Compressor low pressure/overload/high pressure alarm, fan motor overload, overall equipment timing, short circuit, phase loss, over temperature, leakage and other protection |
| Supply Voltage | AC380V±10% 50Hz |
| Cooling method | Water Cold |
